Multiple Displays
HDMI®+VGA+LVDS, Supports multiple displays and offers you an extraordinary visual experience.
Wide Application
It provides a great user experiences with improved productivity.
Rich I/O Interfaces
It contains 2x LAN, 6xCOM, 5x USB2.0,1x USB3.2, display via HDMI®, VGA,1xLVDS catering most market requirements.
Product description

Powered by an Intel® Celeron® processor, this board is compatible with J1900, J1800, or N2940. The BYT-60 mini ITX rated at a TDP of 10W/N2940 at 7.5W and adequate for power-sensitive applications. Single Channel SO-DIMM DDR3L up to 8GB memory to add higher bandwidth and lower latencies for processes. Features with 1×SATA and 1×mSATA (or 2×SATA and mSATA can set as mini-PCIe) for storage. This embedded board has a 1080p HD display via VGA, HDMI®, and eDP/LVDS. It has 7×USB2.0 (max.), 1×USB3.2, 2×LAN (max.), 1×PS/2, 1×LPT, 6×COM (max.), 1×mic-in and 1×line-out, which meets most requirements in the market. It can deliver cutting-edge performance with low power consumption. Provides you the ability of multitasking and enhanced security to help create, increase productivity. Ideal for various applications like transportation, communication, and so on.


    l    CPU: Intel® Bay Trail Celeron® and Atom Processors

    l    Memory: Single Channel SO-DIMM DDR3L up to 8 GB

    l    Display: Intel® HD Graphics via VGA, HDMI®, LVDS/eDP

    l    Ethernet: 10/100/1000Mbps

    l    Storage: SATA2.0, mSATA

    l    Expansion: Mini PCIe, eMMC optional

    l    Power: 12V DC input

Technical Parameters

BYT60 TS.png


*Product has High-Definition Multimedia Interface. All specifications are subject to change without notice.

*The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

*All data is for information purposes only and not guaranteed for legal purposes. Information has been carefully checked and is believed to be accurate however, no responsibility is assumed for inaccuracies.  All other trademarks or registered trademarks are the property of their respective owners and are recognized.
