Powerful Computing Performance

Equipped with the Intel® Alder Lake-N Series N100(4Cores/4Threads, 6MB Cache, 3.40GHz) processor and support for up to 32GB DDR4 memory, the DXALN-10 delivers highperformance computing capabilities. It can efficiently handle demanding tasks such as vision inspection, motion control, and surveillance, enabling smooth and efficient operation in industrial environments.

Reliability and Durability

The fanless construction of the DXALN-10 eliminates the challenges
posed by contaminants and noise commonly found in harsh industrial
environments. This design choice also enhances the Mean Time Between
Failures (MTBF), ensuring greater reliability and an extended lifecycle
for the product.

Versatile I/O Options

With a wide range of I/O ports, including 2x USB3.2, 6x USB2.0, 2x LAN, and 6x COM, the DXALN-10 offers flexibility and compatibility with various industrial devices and equipment.This enables seamless connectivity and integration within existing systems, enhancing productivity and ease of use.

Dual Display Supportd

With support for dual displays via HDMI® and DisplayPort, the DXALN10 industrial mini PC enables improved visualization and monitoring capabilities. This is particularly useful in applications that require simultaneous display of multiple data streams or the monitoring of different processes.

Expand-ability

Industrial mini PC provides expansion capabilities through M.2 slots for WiFi and optional Intel®Integrated Connectivity (CNVi) support.This allows for future upgrades and the addition of wireless connectivity options, ensuring compatibility with evolving industrial requirements and technologies.

Product description

For industrial automation applications demanding powerful computing performance and reliability, the DXALN-10 is the ultimate solution. Powered by the Intel® Alder Lake-N Series N100 processor, this fanless embedded industrial PC offers seamless operation in complex environments.

With its versatile I/O array, flexible expansion capacity, and support for up to 32GB DDR4 memory, the DXALN-10 is optimized for vision inspection, motion control, and surveillance applications. Its robust design, coupled with the elimination of noise and contaminants, ensures an extended life-cycle.

Experience superior performance and cost effectiveness with this industrial mini PC , the ideal choice for industrial automation needs. Supports both Windows 10/11 and Linux operating systems, providing users with options to choose the platform that best suits their requirements. It ensures compatibility, stability, reliability, security, and seamless integration with industrial software, empowering businesses to optimize their industrial automation workflows.

Features

CPU: Intel®Alder Lake-N Series N100 Processor
Memory: Single Channel SO-DIMM DDR4 up to 32GB
Display via: Integrated Graphics via DP, HDMI®
I/O Ports: 2xUSB3.2, 6xUSB2.0. 2xLAN, 6xCOM
Ethernet: 10/100/1000/2500Mbps
Storage: SATA, M.2 for SSD
Dimension: 255mm x 220mm x 60mm
Power: 12V/19V DC-in

*Product has High-Definition Multimedia Interface. All specifications are subject to change without notice.

*The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

*All data is for information purposes only and not guaranteed for legal purposes. Information has been carefully checked and is believed to be accurate however, no responsibility is assumed for inaccuracies. All other trademarks or registered trademarks are the property of their respective owners and are recognized.

Technical Parameters

Downloads

Datasheet_DXALN-10

Drivers Audio_Realtek_ALC897

Drivers LAN_Intel_2.5GbE

Drivers Intel Alder Lake N Series
