Intel® Alder Lake Processor Core i3-N305 or N97
Equipped with an Intel® Alder Lake-N series processor,the IXH-ALN35 delivers exceptional computing power with up to 8 cores and 8 threads. With turbo frequencies reaching up to 3.80GHz, it ensures smooth multitasking and efficient operation for industrial applications.


Rugged Design
IXH-ALN35 with passive cooling operates at -20°C to 60°C, reliable in harsh conditions.



Product description

Discover the Maxtang IXH-ALN35, a compact industrial PC designed to thrive in challenging environments. Powered by the Intel® Alder Lake-N series processor, this dynamic system delivers remarkable performance with up to 8 cores and 8 threads, reaching turbo frequencies of up to 3.80GHz.

Engineered for efficiency, it boasts a low TDP rate of 12W-15W, ensuring optimal energy usage without sacrificing power. With its robust I/O interface—including HDMI®, DP, dual RJ45 gigabit network controllers, six serial ports (4RS232 + 2RS485), and eight USB ports—connectivity options are comprehensive, catering to diverse industrial needs.

Built to last, the IXH-ALN35 features a ruggedized aluminum enclosure and fanless design, safeguarding internal components from dust and debris for uninterrupted performance over an extended lifecycle. Experience unparalleled reliability and versatility with the Maxtang IXH-ALN35—a powerhouse solution for industrial computing demands.

Features
    • CPU: Intel® Alder Lake-N Series Processor

    • Memory: Single Channel SO-DIMM DDR4 up to 32 GB

    • Display: Intel® Integrated Graphics, display via HDMI® +DP

    • Ethernet: 10/100/1000Mbps

    • Storage: SATA3.0, mSATA

    • Expansion: M.2 for Wi-Fi

    • Power: 9V-35V DC input, Phoenix input optional

      ixh aln 35-size io.png

Technical Parameters




*Product has High-Definition Multimedia Interface. All specifications are subject to change without notice.

*The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

*All data is for information purposes only and not guaranteed for legal purposes. Information has been carefully checked and is believed to be accurate however, no responsibility is assumed for inaccuracies.  All other trademarks or registered trademarks are the property of their respective owners and are recognized.
