The CLD-15 Mini-ITX motherboard is a versatile and high-performance solution, powered by Intel® 6th, 7th, 8th, and 9th Gen Desktop Processors with the H310C chipset. Designed for demanding applications, it offers excellent computing power and reliability for digital signage, interactive systems, kiosks, industrial automation, and embedded systems. With support for dual-channel DDR4 memory and Intel Integrated Graphics, the CLD-15 ensures smooth multitasking and supports multiple display outputs, making it ideal for creating compact yet powerful solutions. Its robust design and long-life durability make it perfect for various all-in-one applications that require both performance and efficiency.
CPU: Intel 6th, 7th, 8th, and 9th Gen Desktop Processor
Memory: Dual Channel SO-DIMM DDR4 up to 64GB
Display: Intel Graphics display via HDMI 1.4, LVDS, VGA
Ethernet: 10/100/1000 Mbps
Storage: SATA3.0, mSATA
Expansion: M.2 for WiFi
Power: 19V DC input
*Product has High-Definition Multimedia Interface. All specifications are subject to change without notice.
*The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
*All data is for information purposes only and not guaranteed for legal purposes. Information has been carefully checked and is believed to be accurate however, no responsibility is assumed for inaccuracies. All other trademarks or registered trademarks are the property of their respective owners and are recognized.
Datasheet_CLD15
