AL-35-Maxtang-A premier manufacturer

Intel Alder Lake U Series Processor

Equipped with an Intel Alder Lake-U processor, the SBC-AL35 supports up to 64GB of dual-channel SO-DIMM DDR5 memory, providing enhanced performance and productivity with low power consumption. With the breakthrough hybrid architecture, the 12th Gen Intel Core processors are the first ones to have E-cores and P-cores for multitasking and scalability.

Enhance your results in key industries

The board is excellent for retail, banking, hospitality, education, healthcare, industrial deploys, and video at the edge.

IoT Solutions

Industrial

Transportation

Medical

6COM 8USB 2LAN

The board features six serial ports, eight USBs, and two RJ45 interfaces: 1.0GbE+2.5GbE for high-speed connectivity.

Product description

Introducing our new single board computer (SBC) based on the powerful Intel Alder Lake-U processor. The AL-35 is designed to offer high-performance computing and is energy-efficient. With support for up to 64GB of DDR5 memory and multiple displays via HDMI and eDP/LVDS, the board is well-suited for multimedia applications, such as digital signage and video walls. It also includes dual Ethernet ports, with one 1Gbps and one 2.5Gbps connection, making it ideal for networking and edge computing tasks.

The board offers flexible storage options with SATA3.0, M.2_SATA/4G, and M.2_NVMe interfaces. Additionally, it includes an expansion slot for adding a WiFi module. Powered by a 12V-35V Phoenix input (2Pin), it is versatile enough to be used in a variety of environments.

Features

CPU: Intel Alder Lake-U Processor
Memory: Dual Channel SO-DIMM DDR5 up to 64GB
Display: Integrated Graphics display via 2xHDMI, eDP/LVDs
Ethernet: Intel i219(1.0G)+ Intel i226(2.5G)
Storage: SATA, M.2 for SATA/4G, M.2 for NVMe
Expansion: M.2 for WiFi
Power: 12V-35V Phoenix input(2Pin)
